ENGINEERED
FOR MODERN COMPONENTS
With the ability to provide twice the total system power, 2.5 times the 12V CEM peak power, and three times the rated power of the 12V-2x6 cable for 0.1 ms, random power spikes will never be an issue. The PQ1200G will provide stable and consistent power for legacy and modern power-hungry PCs for the foreseeable future.
THE GOLD STANDARD
80 Plus Gold certified to meet a 92% high level of power efficiency under typical loads of 50%, while Cybenetics and PPLP also rates each PQ1200G unit as Gold as well.
TRUST-WORTHY STABILITY
Through the use of a premium full Japanese electrolytic capacitors, active PFC, half-bridge LLC, and a DC-to-DC topology, the PQ1200G can keep the hold-up time to ≥ 16 ms under a 100% full load—a higher standard than required to meet ATX3.1 compliance.
PCI-E 5.1 PERFECTION
Equipped with a high-grade sleeved 105C-resistant 16AWG copper-core 12V-2x6 cable, the PQ1200G provides up to 600W for modern GPUs.
The PQ1200G comes equipped with a dynamic 120mm FDB fan that will adjust its speed based on the cooling needs of the advanced internal circuitry.
Due to the high quality of the parts utilized, every PQ-G power supply will operate at altitudes up to 5000 meters above sea level.
COMPACT DESIGN
Coming in at an agreeable 140x150x86mm, the PQ1200G can easily fit into the vast majority of cases that support ATX-sized PSUs.
WORRY-FREE COVERAGE
The PQ1200G is engineered and manufactured at such a meticulous level that GAMER STORM is offering a lengthy 10 years of trouble-free limited warranty coverage. Rest assured that if any problems arise during the coverage period, you will be well taken care of.
WORRY-FREE COVERAGE
The PQ1200G is engineered and manufactured at such a meticulous level that GAMER STORM is offering a lengthy 10 years of trouble-free limited warranty coverage. Rest assured that if any problems arise during the coverage period, you will be well taken care of.
Main Power Connector 24 (20+4)Pin x1
x1
SATA x 3 + 4Pin Peripheral x 1
x3
Over Power Protection
Over Voltage Protection
Short Circuit Protection
Over Temp Protection
Over Current Protection
Under Voltage Protection
Surge & Inrush Protection
No Load Operation
